INFERNOWARE™ DISSIPATE
THERMAL DISSIPATION COATING
FEATURES
- Hybrid nanoplatelet thermal dissipation coating for substrates.
- Dissipates heat up to 1600°C (2900°F) from a point heat source.
- Single-part spray application, no catalyst or special application equipment.
- Room temperature air cure formula.
- Very high chemical resistance.
- Compatible with steel, aluminum, glass, plastics, and many other substrate materials.
VIDEO
SPECIFICATIONS AND PERFORMANCE
| Color | Black |
| Dry Film Thickness | 10 – 20 μm (0.4 – 0.8 mil) |
| Solid Content | 40% by weight |
| Coverage | 49 m² (530 ft²) |
| Specific Gravity (cured) | 1.27 ±0.05 g/ml |
| Hardness | 2.5 ±0.5 Mohs |
| Taber Abrasion Resistance | 640 cycles/mil |
| Adhesion (bend test) | >40° |
| Adhesion (cross hatch ASTM B3359) | 5B |
| Max Ambient Temp | 660°C (1220°F) |
| Total Emissivity | 0.96 |
